Built for your installation
Accessories complete an Elausys installation. The CB-10 and CB-15 connection bridges distribute one supply across several actuator channels: 10 mm for the MSA-810, SAE-810 and SAE-2410, 15 mm for the wider terminals of the SAE-816 and HAE-805.
Some alarm gateways need an interface module on the panel side: the Paradox PRT3 serial module for EVO-KNX and the Jablotron JA-121T RS485 interface for JA-KNX. The DIN-2TE enclosure moves a JA-KNX or ANB-KNX gateway from the alarm panel to the electrical cabinet, with a front KNX connector.
See also:The modular actuator systemIntegrating an alarm in KNX
Optional 2 SU DIN-rail enclosure for the Elausys JA-KNX and ANB-KNX gateway boards. Moves the gateway from the alarm panel to the electrical cabinet, with a front KNX bus connector and snap-on clips for 35 mm rail.
Jablotron JA-121T RS485 bus interface for JA-100 series panels, the required companion of the Elausys JA-KNX gateway. Provides the isolated RS485 link the gateway uses to read zones, sections and PG outputs and to arm, disarm and switch PGs from KNX.
Paradox PRT3 serial interface module for EVO and DGP panels, the required companion of the Elausys EVO-KNX gateway. Provides the RS232 ASCII link the gateway uses to read zones, partitions and PGMs and to write the 16 virtual inputs.
Pack of 10 connection bridges, 15 mm pitch, for the Elausys Universal KNX Actuator System. Links the phase terminals of consecutive channels on the wider terminals of the SAE-816 and HAE-805 so one circuit breaker feeds several outputs with a single incoming wire.
Pack of 10 connection bridges, 10 mm pitch, for the Elausys Universal KNX Actuator System. Links the phase terminals of consecutive channels on MSA-810, SAE-810 and SAE-2410 so one circuit breaker feeds several outputs with a single incoming wire.
